PRODUCT
此產品為LED園藝應用設計的集中式電流源，具4000W功率輸出，支援100-300VDC電壓範圍，可提供0-16A無閃爍電流。
| Output Power | 4000 W |
|---|---|
| Dimensions | 480 mm x 140 mm x 40.3 mm |
| Length | 18.86 inches |
| Width | 5.51 inches |
| Height | 1.59 inches |
| Mounting Type | Embedded PSU |
| Maximum Output Current | 16 A |
| Output Voltage Range | 100V to 300V |
| Nominal Output Voltage | 250 VDC |
| Input Range | 187-264 VAC; 311-528 VAC |
| Input Frequency | 47 to 63 Hz (Nominal 50/60 Hz) |
| Efficiency | up to 95.2% |
| Power Factor | 0.98 @ 100% load, at 208VAC |
| Power Density | 38 Watts per cubic inch |
| Inrush Current | <60A Peak at 264/528 VAC |
| Output Adjust Range | 100 VDC to 300 VDC |
| Ripple & Noise (P-P) | 0.5% of Nominal |
| Max Output Capacitance | 600 uF |
| Modules per Shelf | 3 max |
| Warranty | 5 Years |
