PRODUCT
CSU3200 系列產品，詳細規格請參閱下方規格表與原廠型錄，或與我們聯繫取得完整技術資料。
| Output Power | 3200 W |
|---|---|
| Length | 7.28 inches |
| Width | 2.89 inches |
| Height | 1.51 inches |
| Mounting Type | Hotpluggable |
| Maximum Output Current | 262.3 A |
| Output Voltage Range | 12.2 V |
| Standby Output Voltage | 12.0V at 3.5A |
| Minimum Input Voltage | 90 V |
| Maximum Input Voltage | 264 V |
| Input Frequency | 47 - 63 Hz |
| Hold-up Time | 11 ms |
| Power Factor | >0.98 at 50% load |
| Number of Outputs | 2 |
| Features | Redundant mode operation, Field upgradable firmware, Load Sharing, PMBus monitoring, FW security |
| Warranty | 2 Years |
